68 pin male connector diagram and applications

68 pin male used in:

• PC Card ATA bus This specification makes it possible to share ATA & PC Card with the same connectors.
• CardBus 32-bit bus defined by PCMCIA.
• PCMCIA (PC Card) bus The PCMCIA (Personal Computer Memory Card International Association) 16 bit bus


  Associated connector:


  68 pin female used in:

• PC Card ATA bus This specification makes it possible to share ATA & PC Card with the same connectors.
• CardBus 32-bit bus defined by PCMCIA.
• PCMCIA (PC Card) bus The PCMCIA (Personal Computer Memory Card International Association) 16 bit bus
